This 2004A character LCD display module features a classic 20-character x 4-line dot matrix structure, available in blue or green screen. It is equipped with a high-performance SPLC780 controller, fully compatible with the HD44780 instruction set, greatly facilitating your secondary development.Supporting a standard 5V power supply with a low operating current of only 2mA, it offers optional EL or LED backlight for clear visibility in various environments. The module uses a single-row parallel port and conductive rubber strip connection, making installation easy, stable, and reliable.
With its industrial-grade wide-temperature design (-10~+60℃), it can adapt to harsh working environments. It is widely used in industrial automation control, smart meters, smart homes, in-vehicle displays, and various DIY electronic projects, making it an ideal choice for your embedded system development.
Product Parameter
Display Screen: Blue Screen, Green Screen
Operating Temperature: -10~+60°C
Controller: SPLC780
Storage Temperature: -20~+70°C
Operating Current: (excluding backlight) 2.0mA(5V)
Screen Size: 76mmx26mm Interface Type: Single-row Parallel Port
Size: 0.55mmx0.55mm Backlight Type: EL/LED
Character Size: 29.5mmx47.5mm
Display Content: 20 characters x 4 lines Operating Voltage: +5V
Module Dimensions: 98mm x 60mm
Connection Method: Conductive Rubber Strip
Weight: Approx. 68g
The LCD2004A character dot matrix liquid crystal display module features a small size, light weight, low power consumption, and rich display content, and is widely used. It utilizes the property of liquid crystals that they can change the direction of light propagation after being processed, and stimulates the liquid crystal molecules with current to generate dots, lines, and surfaces, which are then combined with the backlight to form the picture. The initial LCD controller used in the LCD2004 module was HD44780, and various LCD manufacturers all provide almost the same 1602 modules or compatible modules, and basically all adopt compatible ICs. Therefore, in terms of characteristics, they are basically the same; of course, many manufacturers provide display modules with different character colors, backlight colors, etc.
The internal structure of the LCD2004 mainly consists of the LCD display screen (LCD PANEL), controller, driver, and bias generation circuit.
